System expansions
2
1
► Push the hard disk drive into the casing (1) until it comes to a stop and ensure
that the E asyC hange rails have securely engaged.
► Connect the cables (
data cable, power supply) t o the drive.
Check that the polarity is correct and do not use any force.
Further information on connecting the da ta cable can be found in the mainboard manual.
► Close the casing (s
ee "
Closing the casing", Page 35).
AMILO Desktop Operating Manual, edition 3 49
