Ports and operating elements
Ports
This chapter presents the individual hardw are components of your device. This will provide
you with an overview of the ports and operating elements on the device. Please familiarise
yourself with these components before starting to work with your device.
Front
8
1
2
3
4
5
6
7
1 = Module bays fo
r5
1
/
4
" dri ves
2 = Module bays for 3
1
/
2
inch slide-in modules
3 = ON/OFF switc
h
4 = Headphone port
5 = Microphone ja
ck
6 = USB ports
7=Harddiskfro
nt panel (removable)
8 = Latch with optional casing lock
