TX100 S2 Service Supplement 111
Replacement routines
Ê Remove the nylon screw from the new UFM board.
Ê Remove the UFM spacer.
Figure 96: Installing the UFM board
Ê Mount the new UFM board to the system board and the remaining UFM
spacer
.
