28 Service Supplement TX100 S2
Replacement routines
4.1.3 Opening and closing the front bezel
4.1.3.1 Removing the front bezel
The following replacement routines require removing the front bezel:
– Replacing the front panel cable
– Replacing the front USB module
Ê Shut down the server and disconnect the AC power cord from the system.
Ê You are advised to
– either bring the server to its upright position
– or lay the server on its side with the chassis slightly elevated above the
detached front bezel.
Ê Remove the side cover as described in section 4.1.1.1 on page 23.
Ê Remove all accessible drives and dummy covers as described in sections
4.1.5.1 on page 39 and 4.1.6.1 on page 41.
I In order to fully remove the front bezel, you first have to disconnect the
front panel cable from the system board and detach it from the cable
cable clamps.
Ê Open the HDD cage as described in section 4.1.2.1 on page 25.
Ê Remove the air duct as described in section 4.1.4.1 on page 33.
Ê Remove the front fan module as described in section 4.6.1 on page 72.
Part number: C26361-K1007-B867
