Fujitsu PRIMERGY TX100 S3 Core Edition User Manual

18 Operating Manual TX100 S3 Core Edition
Functional overview
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3009
Chipset Intel
®
C202
Processor quantity and
type
1x Intel
®
Celeron
®
/Xeon
®
/Pentium
®
/Core i3
processor
Memory slots 4
Memory slot type DIMM (DDR3)
Memory capacity
(min. - max.)
2 GB - 32 GB
Memory protection ECC
Memory notes 1333 MHz memory modules with 2, 4, or 8 GB
USB connectors 9 x USB 2.0 (2x front, 6x rear, 1x internal for backup
device
Graphics (15-pin) 1 x VGA
Serial 1 (9-pin) 1 x serial RS-232
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet

Fujitsu PRIMERGY TX100 S3 Core Edition Specifications

General

Brand	Fujitsu
Model	PRIMERGY TX100 S3 Core Edition
Category	Server
Language	English
