Fujitsu PRIMERGY TX200 S2 Options Guide

106 Options Guide U41593-J-Z156-2-76
Cabling Appendix
Figure 92: Basic cabling
Cable-prefix: T26139-
Power SCSI IDE/FD Data
Legend:
SCSI-HD ID5 SCSI-HD ID4 SCSI-HD ID3 SCSI-HD ID2 SCSI-HD ID1 SCSI-HD ID0
1" HDD
SCSI backplane 1-channel
CD/DVD slimline
Floppy
SCSI device SCSI device
Floppy
Operating panel
USB
IDTEMP
Y3785-V208
Terminator
Y3917-V101/ Y3967-V101
Y1248-V401
Y3662-V10
Y3904-V2
Y2603-V7
D1919
Intrusion sw. Intrusion sw.
Y3736-V2
Y3718-V601
SCSIASCSIB
Parallel port (option)
Y3910-V3
Con3
Con2
External SCSI port (option)
Y3882-V2
option
Y2493-V8
Con5
Con4
Con3 free
Con2 free
Con4
