U41593-J-Z156-2-76 Options Guide 107
Appendix Cabling
Figure 93: Cabling standard power supply E504-V70
Cable-prefix: T26139-
Power
SCSI
IDE/FD
Data
Legend:
SCSI-HD ID5
SCSI-HD ID4
SCSI-HD ID3
SCSI-HD ID2
SCSI-HD ID1
SCSI-HD ID0
1" HDD
SCSI backplane
1-channel
CD/DVD
slimline
Floppy
SCSI
device
SCSI
device
Floppy
IDTEMP
D1919
Standard PSU
E504-V70
P1
P8
P14
P6
P13
P7
P9
P5
P2
P15/P16/P17/P18 not used
P11 not used
P10 not used
P12
P20 not used
free
P3
P4
P19
