Fujitsu PRIMERGY TX200 S2 Options Guide

110 Options Guide U41593-J-Z156-2-76
Cabling Appendix
Figure 96: Cabling hard disks extension box
Cable-prefix: T26139-
Power SCSI IDE/FD Data
Legend:
SCSI-HD ID5 SCSI-HD ID4 SCSI-HD ID3 SCSI-HD ID2 SCSI-HD ID1 SCSI-HD ID0
1" HDD
SCS backplane 1-channel
CD/DVD slimline
Floppy
HD- extension box
Floppy
Operating panel
USB
IDTEMP
Terminator
Y3917-V101/ Y3967-V101
D1919
Y3718-V601
SCSIASCSIB
Con3 free
Con2 free
Con4
Con4
Con3 free
Con5
Con1
Con2
Power backplane
X5
X6
X3
X4
X7
Hot-plug PSU 600 W
Hot-plug PSU 600 W
Con 2
Con 3 frei
Con 4
Con 5
Y3856-V4
Stanadrd PSU: plug P8 (P7 free)
