Fujitsu PRIMERGY TX200 S2 - Page 109

U41593-J-Z156-2-76 Options Guide 109
Appendix Cabling
Figure 95: Cabling hot-plug power supply
Cable-prefix: T26139-
Power SCSI IDE/FD Data
Legend:
SCSI-HD ID5 SCSI-HD ID4 SCSI-HD ID3 SCSI-HD ID2 SCSI-HD ID1 SCSI-HD ID0
1" HDD
SCSI backplane 1-channel
CD/DVD slimline
Floppy
SCSI device SCSI device
Floppy
D1919
Y3856-V4
Hot-plug PSU 600 W
Hot-plug PSU 600 W
Power backplane
X5
X6
X3
X4
X7
Con 2
Con 3
Con 4 Con 5
Y3856-V5
Y3939-V2
Y3697-V103
Y3758-V8
