Fujitsu STYLISTIC Q775 User Manual

Technical da ta
Rechargeable battery
For information on the batteries used in your device, please see
"
http://solutions.us .fujitsu.com/www/content/suppor t/contact/index.php".
3-cell lithium polymer battery 4,250 mAh
Rated voltage 10.8 V
Rated capacity 46 Wh
AC adapter 65 W for the Tablet PC
Technicaldata
Rated voltage 19 Volts
Max. rated current 3.42 A
An additional AC adapter or AC cable can be ordered at any time.
Performance docking cradle (optional)
Electrical data
Safety regulations complied with CE
Protection class III
Ports
Headphone port 3.5 mm stereo mini jack
Microphone port 3.5 mm stereo mini jack
Docking port 40-pin
HDMI port 1 x
VGA monitor port
1x
USB (Uni
versal Serial Bus)
3xUSB3.
0
LAN port 1 x
Security Lock device
1x
Ambient conditions
Environment class DIN IEC 721
7K1
Mech
anism class DIN IEC 721
7M2
Operating tem perature 5 °C .... 35 °C / 41 °F .... 95 ° F
Temperature in transit
–15 °C .... 60 °C / 5 °F .... 140 °F
Fujitsu 99

Fujitsu STYLISTIC Q775 Specifications

General

LED backlight	Yes
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	330 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor code	SR23X
Processor cache	3 MB
Processor cores	2
Processor model	i5-5300U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-5300 Mobile Series
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.3 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.3 mm
Processor front side bus	- MHz
Processor boost frequency	2.9 GHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	- GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	8 GB
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	128 GB
Graphics card	HD Graphics 5500
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
4G standard	LTE
3G standards	UMTS
SIM card type	MicroSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	867 Mbit/s
Mobile network generation	4G
Microphone in	No
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Cable lock slot type	Kensington
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE, FCC, UL-cUL Listed, CB, RF, WEEE, HCT, HCL entry, WHQL
Google applications	Google Maps, Google Play
Password protection type	BIOS, HDD, Supervisor, User
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, Recorder
Platform	Windows
Trial software	McAfee Multi-Access
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	14.5 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	85213
Processor socket	BGA 1168
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	208 mm
Width	317 mm
Height	12.7 mm
Weight	990 g
