Connecting external devices
HDMI port (only with p erformance docking cradle, keyboard
docking station and power keyb
oard docking station)
HDMIport
The HDMI port can be use d to connect an external a mpli er, LCD TV or a
plasma TV with an HDMI conn ection.
Connect the data cable to the
external device.
Connect the data cable to t
he HDMI port.
Some LCD televisions have only two speakers/speaker ports and therefore
cannot reproduce Dolby Digital or DTS. To play back HDMI sound, you
must change the HDMI sound settings accordingly.
You can nd the settings under Control Panel - Hardware and Sound. Deactivate the
settings for DTS Audio and Dolby Digital to enable playback of HDMI sound.
External monitor port (VGA) (only with performance
docking cradle, keyboard docking station and power
keyboard docking station)
An ana log monitor is connected to the analog VGA mo nitor port. Screen output is
limited to a maximum of two screens at the same time.
MonitorVGAportScreenconnectionMonitorconnect io n
Switch off the Tablet PC and the
external monitor.
Plug the data cable of the external
monitor into the monitor port.
First switch on the external monitor and
then switch on the Tablet PC.
You can also switch back and forth betwee n the external monitor and the LCD
screen of the Tablet PC, see "
Touch screen", Page 27.
You can display the same image on the external monitor an d on the LCD
screen of the Tablet PC at the same time.
80 Fujitsu

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu STYLISTIC Q775 and is the answer not in the manual?

Fujitsu STYLISTIC Q775 Specifications

General IconGeneral
LED backlightYes
Display diagonal13.3 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display brightness330 cd/m²
Native aspect ratio16:9
Display number of colors16.78 million colors
Bus typeDMI2
SteppingF0
Tjunction105 °C
Processor codeSR23X
Processor cache3 MB
Processor cores2
Processor modeli5-5300U
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel® Core™ i5-5300 Mobile Series
Processor threads4
Processor codenameBroadwell
Processor frequency2.3 GHz
Processor cache typeL3
Processor lithography14 nm
Processor manufacturerIntel
Processor package size40 x 24 x 1.3 mm
Processor front side bus- MHz
Processor boost frequency2.9 GHz
Processor operating modes32-bit, 64-bit
PCI Express configurations4x1, 2x4
Supported instruction setsAVX 2.0
Thermal Design Power (TDP)15 W
Configurable TDP-down frequency0.6 GHz
Internal memory- GB
Memory clock speed1600 MHz
Internal memory typeLPDDR3-SDRAM
Maximum internal memory8 GB
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB
Internal storage capacity128 GB
Graphics cardHD Graphics 5500
Audio systemRealtek ALC283
Flash typeLED
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
4G standardLTE
3G standardsUMTS
SIM card typeMicroSIM
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi data rate (max)867 Mbit/s
Mobile network generation4G
Microphone inNo
HDMI ports quantity0
Headphone connectivity3.5 mm
USB 2.0 ports quantity1
Device typeTablet PC
Form factorSlate
Product colorBlack, Silver
Cable lock slot typeKensington
Sustainability certificatesRoHS, ENERGY STAR
CertificationCE, FCC, UL-cUL Listed, CB, RF, WEEE, HCT, HCL entry, WHQL
Google applicationsGoogle Maps, Google Play
Password protection typeBIOS, HDD, Supervisor, User
Personal info management (PIM)Alarm clock, Calculator, Calendar, Notes, Recorder
PlatformWindows
Trial softwareMcAfee Multi-Access
Operating system installedWindows 8.1
Operating system architecture64-bit
Battery voltage10.8 V
Battery capacity4250 mAh
Battery life (max)14.5 h
Battery recharge time2.3 h
Number of battery cells3
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current3.42 A
AC adapter output voltage19 V
Storage temperature (T-T)-15 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 85 %
Operating relative humidity (H-H)20 - 85 %
Processor ARK ID85213
Processor socketBGA 1168
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth208 mm
Width317 mm
Height12.7 mm
Weight990 g
