Fujitsu STYLISTIC Q775 User Manual

Working with the Tab let PC
Tablet buttons
In addition to a n on/off switch ( 4), your Tablet PC is fitted with three tablet buttons.
1 2
4
3
No. Description Functions
1
Shortcut button Start function manager or screen shot function
2 Decrease v olume button Decrease volume
3 Increase volume button Increase volume
If the Tablet PC ’s
Windows bu tton is pressed in combination with
the ON/ OF F butto
n (4), this function is equivalent to pressing the
Ctrl
+
Alt
+
Del
key combinati
on on a keyboard.
Webcam
Webcam
Your device has two webcams: one on the front of the device and one on the rear.
The webcam has its own status indicator. The indicator lights up when the webcam is active.
Depending on the software use d, you can use your webcam to take pictures,
record video clips or take part in web chats.
• The picture quality depends on the lighting conditions and the software being used.
• You can only operate the webcam with a particular app lication (e.g. an Internet telephony
program or a video conferencing program which supports a webcam).
• When using the webcam the support of the Tablet PC must not wobble.
• The webcam automatically adjusts itself to the current light level. For this reason,
the touchscreen may flicker while the light level is adjusted.
Further information on use of the webcam and additional settings for your web cam
can be found in the help function of the program using the webcam.
Fujitsu 37

Fujitsu STYLISTIC Q775 Specifications

General

LED backlight	Yes
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	330 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor code	SR23X
Processor cache	3 MB
Processor cores	2
Processor model	i5-5300U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-5300 Mobile Series
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.3 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.3 mm
Processor front side bus	- MHz
Processor boost frequency	2.9 GHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	- GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	8 GB
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	128 GB
Graphics card	HD Graphics 5500
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
4G standard	LTE
3G standards	UMTS
SIM card type	MicroSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	867 Mbit/s
Mobile network generation	4G
Microphone in	No
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Cable lock slot type	Kensington
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE, FCC, UL-cUL Listed, CB, RF, WEEE, HCT, HCL entry, WHQL
Google applications	Google Maps, Google Play
Password protection type	BIOS, HDD, Supervisor, User
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, Recorder
Platform	Windows
Trial software	McAfee Multi-Access
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	14.5 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	85213
Processor socket	BGA 1168
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	208 mm
Width	317 mm
Height	12.7 mm
Weight	990 g
