Working with the Tablet PC
Using the stylus
Pen
1
2
3
1 = stylus tip
2 = stylus button (right mouse button)
3 = eyelet for optional stylus tether
You can use the stylus on your Tablet PC as an electronic writing tool, to select menu items and to
navigate through the programs. Programs that support han dwriting recognition also allow you to
write directly on the screen with the stylus. You can also use the stylus as a drawing tool.
A stylus tether is available as an optional extra and you can use this t o tie the
eyelet on the stylus to the eyelet on the Tab let PC.
Use only the stylus that was provided with your Tablet PC. Do not use any other pointed
object as a substitute, that was n ot specially designed for your Tablet PC . Replace
the stylus tip if it is worn. The warranty does not cover a scratched screen.
While writing, take care that you do not scratch the surface of the
display ( e.g. with a wristwatch or bracelet).
The stylus of th
e Tablet PC is an electronic instrument that can be damaged
if used imprope
rly. Handle the stylus with c are.
Our recommend
ations for proper handling of the stylus are as follows:
Do not gestur
e with the stylus.
Do not use the stylus as a pointer.
Do not use th
e stylus on surfaces other than the screen of the Tablet PC.
Do not try to turn the grip of the stylus. The grip is used to put the
stylus into its slot or to take it out of its slot.
Never stor
e the stylus with its weight on the tip (e.g. with the tip down in a stylus
containe
r). If the stylus is stored with the tip pointing down, this may have an
adverse e
ffect on the stylus mechanism (particularly in high temperatures). In this
case, th
e stylus tip may react as though it is constantly being pressed down. To
avoid da
mage, the stylus should be store d in the slot when not in use.
The stylus can be inuenced by electromagnetic elds (cursor quivers or
jumps). There may be a few areas on the screen whe re the cursor quivers
slightly in spite of pressing the stylus down rmly.
The screen responds to entries made with the tip of the nger or the stylus when the
tip of the nger or the stylus directly touches the screen.
You ca n use the stylus to perform almost all functions f or which you w ould othe rwise use a mou se.
34 Fujitsu

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu STYLISTIC Q775 and is the answer not in the manual?

Fujitsu STYLISTIC Q775 Specifications

General IconGeneral
LED backlightYes
Display diagonal13.3 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display brightness330 cd/m²
Native aspect ratio16:9
Display number of colors16.78 million colors
Bus typeDMI2
SteppingF0
Tjunction105 °C
Processor codeSR23X
Processor cache3 MB
Processor cores2
Processor modeli5-5300U
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel® Core™ i5-5300 Mobile Series
Processor threads4
Processor codenameBroadwell
Processor frequency2.3 GHz
Processor cache typeL3
Processor lithography14 nm
Processor manufacturerIntel
Processor package size40 x 24 x 1.3 mm
Processor front side bus- MHz
Processor boost frequency2.9 GHz
Processor operating modes32-bit, 64-bit
PCI Express configurations4x1, 2x4
Supported instruction setsAVX 2.0
Thermal Design Power (TDP)15 W
Configurable TDP-down frequency0.6 GHz
Internal memory- GB
Memory clock speed1600 MHz
Internal memory typeLPDDR3-SDRAM
Maximum internal memory8 GB
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB
Internal storage capacity128 GB
Graphics cardHD Graphics 5500
Audio systemRealtek ALC283
Flash typeLED
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
4G standardLTE
3G standardsUMTS
SIM card typeMicroSIM
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi data rate (max)867 Mbit/s
Mobile network generation4G
Microphone inNo
HDMI ports quantity0
Headphone connectivity3.5 mm
USB 2.0 ports quantity1
Device typeTablet PC
Form factorSlate
Product colorBlack, Silver
Cable lock slot typeKensington
Sustainability certificatesRoHS, ENERGY STAR
CertificationCE, FCC, UL-cUL Listed, CB, RF, WEEE, HCT, HCL entry, WHQL
Google applicationsGoogle Maps, Google Play
Password protection typeBIOS, HDD, Supervisor, User
Personal info management (PIM)Alarm clock, Calculator, Calendar, Notes, Recorder
PlatformWindows
Trial softwareMcAfee Multi-Access
Operating system installedWindows 8.1
Operating system architecture64-bit
Battery voltage10.8 V
Battery capacity4250 mAh
Battery life (max)14.5 h
Battery recharge time2.3 h
Number of battery cells3
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current3.42 A
AC adapter output voltage19 V
Storage temperature (T-T)-15 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 85 %
Operating relative humidity (H-H)20 - 85 %
Processor ARK ID85213
Processor socketBGA 1168
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth208 mm
Width317 mm
Height12.7 mm
Weight990 g
