Fujitsu STYLISTIC Q775 User Manual

Contents
Removingthememorycard .......................................................... 41
SIMcard ............................................................................... 42
InsertingaSIMcard ................................................................. 42
RemovingaSIMcard ............................................................... 43
WirelessLAN/Bluetooth/4G/LTE/NFCwirelesscomponents ................................. 43
Switching the wireless components on and off ......................................... 43
ConfiguringWLANaccess ........................................................... 43
FurtherinformationonWLANandBluetooth ........................................... 44
AccessviaUMTS ................................................................... 44
AccessviaWirelessWAN ............................................................ 44
Accessvia4G ...................................................................... 44
NFC (Near Field Communication, optional) . . . ......................................... 44
Ethernet and LAN (only with performance docking cradle, keyboard docking station and power
keyboard docking station) ................................................................ 45
GPS ................................................................................... 45
Accessories fo r your Tablet PC (optional) . ............................................. 46
Your performance docking cradle (optional) . . ............................................. 47
Cradle components . . ................................................................ 47
Settingupthecradle ................................................................ 47
Connecting the Tablet PC to the cradle . . ............................................. 48
Disconnecting the Tablet PC from the cradle . ......................................... 49
Keyboard docking station or power keyboard docking station (optional) . . . ................... 50
Ports on the keyboard docking station or power keyboard docking station . ............... 51
Connecting th e tablet PC to the keyboard docking station or powe r keyboard docking
station .............................................................................. 53
Disconnecting the tablet PC from the keyboard docking station or power keyboard docking
station ............................................................................. 54
Removable rechargeable battery for the power keyboard docking station (optional) . . . .... 55
Intermediary VESA Mount Plate (optional) . . . ............................................. 58
Hand strap (optional) . . . . ................................................................ 60
Shoulder strap (optional) ................................................................ 62
Folio case (optional) . . . . . ................................................................ 64
Protective TPU cover with hand strap (optional) . . ......................................... 65
Prepare installation . . ................................................................ 65
InserttheTabletPCintheprotectiveTPUcover ....................................... 66
Connecting the Tablet PC to the keyboard docking station or cradle . . ................... 68
Securityfunctions ..................................................................... 69
Configuring the fingerprint sensor ........................................................ 70
Using the palm vein sensor (device-depe ndent) . . ......................................... 71
UsingtheSecurityLock ................................................................. 73
ConfiguringpasswordprotectioninBIOSSetupUtility ...................................... 73
Protecting BIOS Setup Utility (supervisor password a nd user password) . . ............... 74
Password protection for booting the operating system .................................. 75
Passwordprotectionfortheharddisk ................................................. 76
SmartCard reader (optional) . ............................................................ 77
InsertingtheSmartCard ............................................................. 77
Trusted Platform Module - TPM (device dependent) . . . . . . .................................. 78
EnablingTPM ....................................................................... 78
DisablingTPM ...................................................................... 78
Connectingexternaldevices ........................................................... 79
Connecting an external monitor . . ........................................................ 79
4 Fujitsu

Fujitsu STYLISTIC Q775 Specifications

General

LED backlight	Yes
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	330 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	DMI2
Stepping	F0
Tjunction	105 °C
Processor code	SR23X
Processor cache	3 MB
Processor cores	2
Processor model	i5-5300U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-5300 Mobile Series
Processor threads	4
Processor codename	Broadwell
Processor frequency	2.3 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	40 x 24 x 1.3 mm
Processor front side bus	- MHz
Processor boost frequency	2.9 GHz
Processor operating modes	32-bit, 64-bit
PCI Express configurations	4x1, 2x4
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	- GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	8 GB
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Internal storage capacity	128 GB
Graphics card	HD Graphics 5500
Audio system	Realtek ALC283
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
4G standard	LTE
3G standards	UMTS
SIM card type	MicroSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	867 Mbit/s
Mobile network generation	4G
Microphone in	No
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Cable lock slot type	Kensington
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE, FCC, UL-cUL Listed, CB, RF, WEEE, HCT, HCL entry, WHQL
Google applications	Google Maps, Google Play
Password protection type	BIOS, HDD, Supervisor, User
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, Recorder
Platform	Windows
Trial software	McAfee Multi-Access
Operating system installed	Windows 8.1
Operating system architecture	64-bit
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	14.5 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	85213
Processor socket	BGA 1168
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	208 mm
Width	317 mm
Height	12.7 mm
Weight	990 g
