12. 2. 2 Dismounting and cleaning
 Unscrew the spindle of the viscometer axis and lower the spindle slowly in the sample container (K).
Caution on removing the spindle, it can be hot due to a previous high temperature
experiment.
 Remove Adapter (G) from metallic glass.
 Place the viscometer upright. Remove the upper stopper (N).
 Remove the spindle carefully (L).
 Unscrew the bottom stopper (M) and remove the container (K) from below the thermostatic flow
jacket (J).
 Remove the container, wash it or use compressed air. Wash the circulation jacket too if necessary.
 Remove Adapter (G) from the circulation jacket.
Important:
Do not use any cleaner or tool that can damage the metallic surface. Make sure you only use liquids that
agree with the APM adapter material!
Solvents that can be used: water, ethanol or high concentrations of alcohol. For other solvents, check the
chemistry compatibility table.
12. 2. 3 Technical specifications of APM and APM/B
Measurement range:
 Model L: 1.5* to 200 000 mPa.s
 Model R: 25* to 3 300 000 mPa.s
 Model H: 0.2* to 26 660 Pa.s
* Measurement representing 10 % of the full scale.
Spindles features and APM filling:
 L Model & TL spindles
Spindle
Shear rate [ s
-1
] *)
Sample volume [ ml ]
Container
TL5
1.32 x RPM
6.7
STC
TL6
0.34 x RPM
9.0
STC
TL7
0.28 x RPM
9.4
STC
TL8
0.29 x RPM
4.2
TL8C
TL9
0.22 x RPM
16.0
STC
