6 Modifications to the basic vehicle
6.12 Handling of EV system
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
6.12.6 Installing the side underrun protection
(a) When installing the side underrun protection in the
vicinity of the high-voltage battery box, take care
that it does not interfere with the replenishment of
water in the inverter cooling water tank, the
inspection of the filling port and the high-voltage
battery box side cover, or the operation of the high-
voltage shutoff switch.
(b) Ensure that the side underrun protection and
mounting stay do not hide the access hole for the
high-voltage shutoff switch in the side cover or the
caution labels.
6.12.7 Precautions during painting
(a) High-voltage cables and connectors are in
exclusive orange color so that they can be
identified as high-voltage. When reapplying
painting, be careful not to paint these cables so
that they can be surely distinguished.
(b) The high-voltage battery box is painted in color so
that the rise in the battery temperature is kept to a
minimum. Do not repaint the battery box.
6.12.8 Attaching caution label for high-voltage
shutoff switch
6.12.9 Installing custom-built truck body
When adding a wire or pipe for installing custom-built
body, do not clamp it together with a high-voltage
cable.
i Additional information
For attaching of the caution label, see É 10.8.2.
