8.7 Lighting
8.7.1 Installation of Additional lamps and
equipment
•Turn signal lamps
One lamp (*1) may be added on one side (*1:
voltage 12 V, lamp specifications 21 W).
The addition of the lamp may result in the open
circuit detection function being inoperative. Use
the specified additional lamp.
After modification, be sure to perform the
functional check.
When you install additional turn lamp, ask an
authorized MITSUBISHI FUSO dealer to change the
parameters of the SAM control unit.
• Installing rear lamps
(1) The vehicle is shipped with the rear
combination lamp, backup lamp, and license
plate lamp temporarily mounted on the chassis.
Use those parts.
(2) Be sure to install the lamps on each side of the
vehicle symmetrically. Fix lamp wires aesthet-
ically nicely along the rear surfaces of the
frame, cross member, and rear body by using
adequate clamps.
• Rear combination lamp
(1) Installation
On the chassis with a cab, the rear combination
lamp has been temporarily mounted upside
down and the water drain hole in the lamp has
been taped. Be sure to peel off the tape after
the lamp is installed in the correct position.
Do not array the lamp vertically.
(2) Harness extension
The extension harness for the rear combination
lamp is available now. please use it.
Unit: mm
• License plate holder
(1) For the license plate lamp, use the lamp
provided with the chassis as far as possible.
(2) The law stipulates that the license plate bracket
must be of a construction such that it cannot be
easily removed from the rear body. For this
reason, install the bracket with rivets, or bolt
the bracket by tightening the nuts and then be
sure to either crimp the threaded part of each
bolt or weld the nut to the bolt.
(3) When installing the license plate brackets to the
wooden part of the rear body, use bolts that are
of sufficient length to pass completely through
the wood, and after tightening the nuts be sure
to crimp the threaded part of each bolt.
(4) Select the mounting position of the license
plate in such a way that the license plate is not
in the shadow of the rear bumper or any of the
lamps.
• Installation of side reflectors
Remove side reflectors from the frame during body
building for later use. For additional requirements,
use MITSUBISHI FUSO genuine parts.
The front side reflector, removed from the frame,
can no longer be reused. Use a new part if
replacement is necessary for a damage one.
i Additional information
Failure to change the parameters will result in the
turn signal not operating properly.
Application Length Part No.
Extension harness for
rear combination lamp
400 MC115366
900 MC115367
