8.2 Electric wiring
8 Electrics/electronics
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
8.2 Electric wiring
8.2.1 General precautions
The vehicle is delivered after electric wiring and fuses
on the chassis side are checked with respect to load
capacity, frequency of use, etc. to make sure of fire
prevention and running safety. Do not alter the wiring
unless it is absolutely necessary. Should it become
unavoidable to extend or modify the wiring, be sure to
follow the instructions given in "8.2 Electric Wiring".
8.2.2 Cable Identification
Cable size and cable color
Coding system
Alphabetical symbols of cable colors Typical examples of cable identification codes
1 Type of cable
(this may not be omitted in case of AV line)
2 Cable size (nominal sectional area)
3 Cable color (base color)
4 Cable color (stripe color)
Symbol color Symbol color
W WHITE L BLUE
B BLACK Br BROWN
R RED Lg LIGHT GREEN
Y YELLOW O ORANGE
G GREEN
a
•0.85 – GW
•AVX1.25 – L
b
c
d
e
f
a
Stripe color: White
b
Base color: Green
c
Cable size: 0.85 mm
2
d
Base color: Blue (no stripe color)
e
Cable size: 1.25 mm
2
f
Type of cable: AVX line
