8.2 Electric wiring
8 Electrics/electronics
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
Select types of cables
Related standards
(JIS C 3406: Low voltage cables for automotive use)
(JASO D 608: Heat-resistive low voltage cables for
automotive use)
(JASO D 609: Current capacity of low voltage cables
for automotive use)
Type of cable
Select necessary types of cables from the list below.
Cable size
Select necessary cable sizes from the list below.
"f" suffixed to nominal sectional area stands for
"flexible."
Use flexible cables in vibrating and crooked areas,
such as at the cab to chassis and transmission.
Type of cable Location of use
AV line
Vinyl-insulated low voltage cable for automotive use
Used for ordinary wiring
AVX line
Cross-linked vinyl heat-resistive low voltage cable for
automotive use
Used for wiring in areas where ambient temperature
is high, such as around motor generator and EV
battery
AEX line
Cross-linked polyethylene heat-resistive low voltage
cable for automotive use
Nominal sectional area
Number of strands
/Strand diameter (mm)
Allowable current (A)
AV line AVX line AEX line
0.5f 20/0.18 8 7 7
0.5 7/0.32 9 8 8
0.75f 30/0.18 10 9 9
0.85 11/0.32 11 10 10
1.25f 50/0.18 14 13 13
1.25 16/0.32 14 14 13
2 26/0.32 20 18 18
3 41/0.32 27 25 25
5 65/0.32 36 34 33
8 50/0.45 47 44 43
