6 Modifications to the basic vehicle
6.2 Chassis frame material
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
6.2 Chassis frame material
If the frame is extended, the material of the extension
element and reinforcing bracket must have the same
quality and dimensions as the standard chassis frame.
Material/part
Side rail Stiffener a Stiffener b Stiffener c Stiffener
MJSH440
(S355J2C+N)
HTP540
(S500MC)
MJSH440
(S355J2C+N)
HTP540
(S500MC)
MJSH440
(S355J2C+N)
MJSH440
(S355J2C+N)
— ì ì ì — —
i Additional information
For the member dimensions and the position of
stiffener a or stiffener b, c, refer to "10.5.2
Frame section modulus" É 10.5.2.
For further information of the material, refer to
"7.1.1 Body mounting methods" É 7.1.1.
