5 Damage prevention
5.5 Painting work
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
5.5 Painting work
General precautions
• If you removed parts, be sure to reinstall them in
their original positions.
• If you removed any labels, obtain new labels and
apply them to the same positions from which you
removed the old labels.
• Paint compatibility should be checked when
repainting. In order to avoid color variations on
painted bodies, MITSUBISHI FUSO recommends
that paints be used only if they have been tested
and approved for the vehicle model in question.
There may be paint colors and parts not available
for some vehicle types. Contact an authorized
MITSUBISHI FUSO dealer to confirm which colors
or parts are available for the vehicle.
5.5.1 Areas which must not be repainted
If you repaint the following parts and areas, trouble
may occur. For this reason, before repainting the body
areas, apply masking tape or other protective material
to these areas to prevent them from being exposed to
paint.
If you removed parts, be sure to reinstall them in their
original positions. Also, if you removed any labels,
obtain new labels and apply them to the same
positions from which you removed the old labels.
• Sealing surfaces
•Windows
• Cotact areas between the wheels and wheel hubs,
contact areas between the disc wheels of the
double tires
• Contact areas for wheel nuts
• Brake hose and brake associated parts
• Various vinyl tubes and identification tape
• Breathers on axles, etc.
• Door locks
• Door retainers in the rear door hinges
• Spring mounting area
• Rubber hoses
• Cab suspension, motor generator, chassis
suspension and steering system rubber or plastic
parts
• Electric control unit
SAM (Body electronics control unit with integrated
relay and fuse)
• Electrical wiring and connectors
• Lamps, switches, batteries and other electrical
parts, high-voltage equipment and other related
parts
• Drive shaft connecting flange (propeller shaft)
• Piston rods for the hydraulic and pneumatic
cylinders
• Control valves for the air lines
• Various caution plates and nameplates
• Rubber or polypropylene parts for cab
• Weatherstrips
• Rear view mirror bodies
•Mud guard aprons
•Washer nozzles
• Splash aprons
•Mud guards
•Steps
•Fenders
• Runchannels
• Bumper corner covers
• Packing rubbers (mirror fitting, aerial fitting,
and grip fitting bases)
•Aerial
• Rader Cover
• The following parts should not be repainted for
appearance reasons.
• Emblems (such as FUSO)
• Rear view mirror stays
•Fenders
• Wiper arms and blades
• Aerial and its bracket
• High-voltage battery box side cover
Environmental note
Paints and lacquers are harmful to health and to the
environment if they are not handled correctly.
Dispose of paints and lacquers in an
environmentally responsible manner.
