8.7 Lighting
8 Electrics/electronics
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
8.7.2 Side reflector
The side reflectors must be removed before starting
the body mounting work.
If any additional side reflectors are to be installed, be
sure to use MITSUBISHI FUSO genuine reflectors.
Side reflector
Front side reflector
10 23
Ø
58
Ø
47.9
10°
10°
Ø
47.9
45°
45°
N82.10-2821-00
1
4
5
2
3
1Front
2 Reflecting section
3 Reflecting section
4Upward
5Bolt M5 × 0.8
Tightening torque: 2 - 3 Nm
530
N82.10-2822-00
2
1 3
4
610
1 Cab with standard width
2 Trailing edge of reflective section of reflector
3Wide cab
4 Trailing edge of reflective section of reflector
