10 Technical data
10.4 Chassis cab drawings
T10
MITSUBISHI FUSO body/equipment mounting directives for eCanter Issue date: 20. 10. 2020
! Only print out complete sections from the current version
10.4.3 Cab side view
A :Front axle center
to cab tilt center
B :Front axle center
to cab end
C :Top surface of frame
to cab tilt center
FEB 965 525 65
unit(mm)
