4 Technical threshold values for planning
4.1 Vehicle overhang and technical wheelbases
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
4.1.1 Maximum vehicle overhangs
a Vehicle with body whereby no load extends over the
rear end of the vehicle.
Example: box body
b Vehicle except a
R=Wheel base
U=Rear overhang
Maximum vehicle overhang (U)
a 65% of wheelbase
b 50% of wheelbase
i Additional information
All national laws, directives and registration
requirements must be complied with.
N60.10-2256-00
RU
R
U
1
2
