61
5 Damage prevention
5.4 Bolted connections
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
• Hex flange nut
Unit: N·m {kgf·m}
Strength
category
4T
Indication
Nominal
diameter
mm
Standard thread Coarse thread
M6 4 to 6 {0.4 to 0.6} —
M8 10 to 15 {1.0 to 1.5} —
M10 21 to 31 {2.1 to 3.1} 20 to 29 {2.0 to 3.0}
M12 38 to 56 {3.8 to 5.5} 35 to 51 {3.5 to 5.2}
