Auxiliary Channel "CH3","CH4"
Auxiliary Channel "CH3","CH4"
The channel 3/4 servo position can be set from the transmitter. When CH3 is assigned to a
dial by the dial function (p.101), this setting is linked to that dial.
When CH3/4 is not assigned to a dial, it can be set with this screen.
When CH3/4 is assigned to a switch by the switch function (p.99), you cannot adjust the
CH3/4 via the screen.
When CH3 or CH4 is assigned by mixing function, channel operation cannot be performed
at this screen.
Setup Item
Channel 3 position
Channel 4 position
Channel 3: Dual ESC mixing
Channel 4: Steering mixing
1
(Position adjustment)
Use the (+) and (-) buttons to adjust the channel 3 or chan-
nel 4 position.
2
When ending setting, return to the initial screen by pressing
the (END) button twice (for function menu screen, press the
(END) button once).
Channel 3/4 adjustment
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Press the (+) and (-) buttons
simultaneously (approx. 1 sec)
to return to the initial screen
Channel 3 position (POSI)
Channel 4 position (POSI)
0~100%
Initial value: 100%
