HOME
screen
MC Link Function (ESC Link)
or
MENU 2 screen
MENU 1
screen
Communication port
Cover
Battery
Connecting ESC receiver
connector to the transmitter
Communication port.
Setup item (before it reads)
Read
Reset
Setup item (after it reads)
Read
Write
Reset
Data list
-Also connect the battery at the ESC side.
MC Link Function (ESC Link)
This is a special function which allows Futaba motor controller (MC) data changes to be set
by the T4X transmitter (MC960CR, MC950CR, MC851C, MC602C, MC402CR, etc.).
However, some data changes require a PC and Link software.
This function is used by connecting ESC directly to the transmitter.
Use the various optional servo extension cords according to the distance between the transmitter
and ESC.
