9
Install the assembled steering wheel
unit and APA to the transmitter using the
screw (3.0x12mm cap screw) supplied.
(Using a 2.5 mm hex wrench.)
8
Install the assembled steering unit to the
transmitter body.
Install slowly so that the wiring is not pinched.
Installation is easy if inserted in A B order.
1
Slowly pull out the PS5 switch cap and
mounting plate in the arrow direction.
Be careful that the switch body does not get
caught and damaged.
2
Next, remove the opposite side charge
unit. Refer to the gure and secure the
arrow part with tape, etc.
The tape is removed at the end of left-hand modi-
cation.
• Obtain 2.5mm hex wrenchs.
• Refer to 1-2 (P24) of the APA for the wheel position change installation method and remove the wheel unit. Only
remove the 15WIRE connector. (See p.26)
Modifying for left-hand use
To Next Page
