100
Returntotableofcontents
LINKAGE MENU
The number of chan-
nels varies depending
on the selected sys-
tem.
Tap to change page.Tap to change page.Tap to change page.
Channel Limiter
7KHFKDQQHOOLPLWHUIXQFWLRQOLPLWVWKHPD[LPXPVHUYRPRYHPHQW%\VXSHULPSRVLQJ
PL[LQJ WKH OLQNDJH FDQ EH SURWHFWHG E\ VHWWLQJ WKH OLPLWHULQ FDVH VHUYRPRWLRQ EH-
FRPHVXQH[SHFWHGO\ODUJH
(Preparation)
- Tap the travel button of the channel you want to set. Value input
buttons appear on the screen.
1
Use the [+] or [-] buttons to adjust the servo angle.
Channel limiter adjustment
2
When finished, return to the Linkage menu screen by pressing the HOME button.
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Limiter rate
0~145
Initial value: 145
Home screen Menu screen
Menu-1 Menu-2
Channel limiter
Linkage menu screen
