TELEMETRYMENU
Sensor List
This menu registers the telemetry sensors used with the transmitter. When only one of
a certain type of sensor is used, this setting is unnecessary, and the sensor can be used
by directly connecting it to the S.BUS2 port of the transmitter.
When using two or more of the same kind of sensors, they must be registered here.
Home screen
Menu screen Telemetry menu screen Sensor list
6HUYRVFODVVL¿HGE\
"
CH
"
EXWVHQVRUVDUHFODVVL¿HGLQXQLWVFDOOHG
"
slots
"
. There are
slots from No. 1 to No. 31. Using a sensor that uses two or more slots, the required
number of slots is automatically assigned by setting up a start slot. When two or
more of the same kind of sensor are used, the sensors themselves must allocate un-
used slots and memorize that slot.
What is a slot?
sensor
The required number of
slots
The number which can be used as a start slot
TEMP (SBS-01T) 1 slot 1~31
RPM (SBS01RM) 1 slot 1~31
Voltage (SBS-01V)
2 slot
1,2,3,4,5,6,8,9,10,11,12,13,14,16,17,18,19,20,21,
22,24,25,26,27,28,29,30
Current (SBS-01C)
2 slot
1,2,3,4,5,8,9,10,11,12,13,16,17,18,19,20,
21,24,25,26,27,28,29
GPS (SBS-01/02G) 8 slot 8,16,24
About the slots that can be used.
- As shown in the table below, the current sensor requires three consecutive slots, and the GPS sensor requires 8
consecutive slots. The GPS sensor (SBS - 01/02G) has a starting slot of 8.16.24.
Sensor is not registered
in slot.
Slot
State with registered sensor
Change to "---------", you can make it
an empty slot.
Slot number
