FUTABA T10PX - Servo View

74
Returntotableofcontents
LINKAGE MENU
The number of channels varies depending
on the selected system.
Servo View
The servo operation of each channel can be checked. Process of the steering angle ad-
MXVWPHQWZKHQDPL[LQJIXQFWLRQZDVVHWHWFFDQHDVLO\FRQ¿UPLW
1
Operating each channel, such as a steering wheel or throttle trigger, the graph moves, and
the servo operation can be confirmed.
2
When finished, return to the Linkage menu screen by pressing the HOME button.
Confirm operation
Home screen Menu screen
Menu-1 Menu-2
Servo view
Linkage menu screen
