Optional Parts
The following parts are available as T10PX options. Purchase them to match your application. For other op-
tional parts, refer to our catalog or web site. http:www.rc.futaba.co.jp
Transmitter Battery
When purchasing a transmitter battery use the following:
Part name
LT2F2000B (7.4 V/2000 mAh) LiPo battery
HT5F1800B (6 V/1800 mAh) NiMH battery
FT2F1100B (6.6 V/1100 mAh)/FT2F1700BV2 (6.6 V/1700 mAh)/2100BV2 (6.6 V/2100 mAh) LiFe battery
Do not use the transmitter batteries as the receiver’s battery.
Since the transmitter's battery has an overload protection circuit, the output power will be shut down when
the high current load is applied. This may result in runaway or fatal crash.
Telemetry sensors
Usable sensor options (As of 2021)
9ROWDJH6HQVRU6%690HDVXUHVH[WHUQDOSRZHUVXSSO\YROWDJHVXSWR9
-Temperature sensor (SBS-01T) Perfect for engine head, etc.
-Temperature sensor (SBS-01TE) Used by attaching to a motor, etc.
-RPM Sensor (SBS-01RM) Measure the rotation speed over the 0 to 999,900 rpm range.
-RPM Sensor (SBS-01RB) Measure the rotation speed over the 360 to 300,000 rpm range. (Brushless type)
&XUUHQWVHQVRU6%6&0HDVXUHVH[WHUQDOSRZHUVXSSO\YROWDJHVXSWR9FDSDFLW\DQGFRQVXPSWLRQFD-
pacity.
-GPS sensor (SBS-01G/02G) Speed and Distance
ExampleofinstallinganglespacerAnglespacer
Angle spacer (10 deg)
The 10 degree angle spacer is available as an option.
