17
Returntotableofcontents
PD1PD2
SW: Push switch PD: Paddle switch DL: Dial
SSW: Slide switch
The position of various switches. The assignment of each function can be changed for
T10PX.
When replacing the trigger spring
Remove the trigger unit, there is a window at the spring.
First, loosen the trigger spring tension
to the maximum, remove the spring
from the window with tweezers, etc.,
and replace it.
P
SW5/DL1SW3
SW1
SW2
SSW1
BPS:SW4
SW6
SW7
Grip Rubber
It is possible to make the narrow
grip by replacing it with the at-
tached grip rubber.
Trigger Guard
Change the shape by replacing it
with the attached trigger guard.
Griprubber
Triggerguard
Change the grip holding
Loosenthetriggerspring
tensiontothemaximum
