When finished, return to the Mixing menu screen by pressing the HOME button twice.
(Preparation)
-Tap the curve type and select [Curve].
1
[Curve rate adjustment ]
2
[Add and remove points ]
3
[Combination/Separate]
Carve adjustment
Tap [
◀◀
] [
▶▶
] to move the cursor line over
the point. Tap the rate setting value to adjust the
curve rate of each point.
You can add points up to 21 points. Tap [
◀
] [
▶
]
or [
◀◀
] [
▶▶
], move the cursor line to the
position where you want to add / delete points,
and tap [ON / OFF].
Curves can be set independently on the left and right sides of the
steering.
[
Combination
] [
Separate
]
Adjustment rate
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Add points
- Select point with the [
◀
] or [
▶
]
buttons.
Add points
- Turn [ON]
Remove points
- Turn [OFF]
Curve rate
0~100
MIXINGMENU
