TELEMETRYMENU
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Setting
- Tap (ON)/(OFF).
Telemetry: Receiver Battery Voltage
This function displays and sets the receiver power supply battery. The sensor sold sepa-
rately does not have to be installed. The transmitter’s initial status voltage is also dis-
played. For a description of the alarm set when the voltage drops, see the description of
the procedure on this page.
Telemetry
Current receiver battery voltage
The Speech function (ON/OFF)
The minimum and maximum when
powering ON are shown.
Sets the limiter voltage
(Voltage that sounds an alarm)
Alarm/vibrator ON/OFF and type
setting (The
arrow indicates that an
alarm is generated when the power
supply voltage drops below the set
value.)
1
(Limit adjustment)
Tap the [Limit]. Value input buttons appear on the screen.
Use the [+] or [-] button to adjust the limit voltage.
2
(Alarm function setup)
Tap the [Alarm] type and select [Inhibit], [Buzzer]or [Voice].
"Inhibit": No audible alarm
"Buzzer": Audible alarm
"Voice": Voice alarm
3
(Vibrator function setup)
Tap the [Vibrator] type and select [Inhibit], [Type 1], [Type 2],
or [Type 3].
"Inhibit": No active vibration
"Type 1": Continuous vibration
"Type 2": Intermittent vibration for a long time
"Type 3": Intermittent vibration for a short time
4
(Speech function setup)
Tap the "Voice" (ON) or (OFF) to select ON/OFF.
"OFF": No voice guide
"ON": Information loaded by voice
5
When finished, return to the Telemetry screen by pressing the HOME button.
Alarm and Vibrator function setup
Setting
- Tap alarm type.
Inhibit/Buzzer/Voice
Setting
- Tap Vibrator type.
Inhibit/Type 1/Type 2/Type 3
*The voice guide loading inter-
val is set by sensor menu.
