TELEMETRYMENU
Telemetry: The Drive Battery Electric Current
When the SBS-01C (electric current sensor) sold separately is mounted on the vehicle,
the electric current, voltage, and consumption capacity of the power battery, etc., can
be displayed.
* A drive battery electric current sensor must
be installed in the model car. Install and con-
nect the sensor following the sensor instruc-
tion manual.
Telemetry
Current drive battery electric
current
Reset consumption capacity
The Speech function (ON/OFF)
The minimum and maximum
when powering ON are shown.
Alarm and vibrator ON/OFF and
type setting (The
arrow indicates
that an alarm is generated when
the electric current drops below
the set value and the
arrow indi-
cates that an alarm is generated
when the electric current exceeds
the set value.)
Current drive battery voltage
Reset consumption capacity
The Speech function (ON/OFF)
The minimum and maximum
when powering ON are shown.
Alarm and vibrator ON/OFF and
type setting (The
arrow indicates
that an alarm is generated when
the battery voltage drops below
the set value and the
arrow indi-
cates that an alarm is generated
when the battery voltage exceeds
the set value.)
Reset consumption capacity
The Speech function (ON/OFF)
The minimum and maximum
when powering ON are shown.
Alarm and vibrator ON/OFF and
type setting (The
arrow indicates
that an alarm is generated when
the battery capacity drops below
the set value and the
arrow
indicates that an alarm is gener-
ated when the battery capacity
exceeds the set value.)
-Upper side:
Current current/voltage/con-
sumption capacity display.
-Lower:
This is a display of the mini-
mum value/maximum value
of the measured current/volt-
age/consumption capacity
after turning on the transmit-
ter power.
* Tap the min/max display but-
ton to restart the measure-
ment.
Th
Th
e
i
mi
i
ni
mum an
d
d
ma
i
xi
mum
Current drive battery capacity
