FutureLogic GEN3 Evolution - RS232 Evaluation Cable; Figure 5-4 RS232 Evaluation Cable

Operators and Technicians Manual
 2011 – 2014 FutureLogic, Incorporated. All Rights Reserved. MNL Page 13 04/10/2014
MNL-000067 REV.X03
RS232 Evaluation Cable
The Evaluation Cable connects the printer outside of the machine. It has a 24Vdc power input port and a
standard RS232 COM (DB9) port for PC communications.
Figure 5-4 RS232 Evaluation Cable
1
2
3
1
5
P/N 150
-00013-100
Bezel LED Port
DB9 RS232 Port
Pin
Function
Pin
Function
1
No connect
6
DTR
2
TX
7
No connect
3
RX
8
RTS
4
No connect
9
No connect
5
GND
Power Port
shield ring – 4
2
1
3
Pin
Function
Pin
Function
1
No connect
8
No connect
2
No connect
9
Modulated +24VDC
3
No connect
10
GND
4
No connect
11
RS232 RXD
5
GND
12
RS232 TXD
6
+24 VDC
13
DTR
7
GND
14
RTS
Pin
Function
1
Modulated +24VDC
2
No connect
3
GND
7
8
1
14
Pin
Function
1
+24VDC
2
GND
3
No connect
Base Port
