Operators and Technicians Manual
2011 – 2014 FutureLogic, Incorporated. All Rights Reserved. MNL Page 35 04/10/2014
MNL-000067 REV.X03
Appendix A Technical Specifications
Introduction
This appendix identifies the general specifications of the printer.
Printer Specifications
Dimensions (WxDxH) 110mm x 304.8mm x 64.3mm
Weight 2.7 lbs
Power Requirements These units are to be supplied by Listed or IEC Certified Power Supplies, rated 24
VDC, minimum 3.2 A, marked “Class 2” or “LPS”.
Sensors Printer Tray, Lid Open, Ticket Taken, Ticket Low, Paper Out/Index Mark (Includes a
Host Controllable Buzzer)
Printing Speed 203mm/Second (8”/Second)
Print and Present 0.95 Second
Printing Width 62mm (true near-edge printing)
Storage 450 Tickets
Ticket Tray Extenders Interchangeable, 900 Ticket Tray
Resolution 8 dots/mm (203 dpi)
Firmware Application in Memory is Reprogrammable (via Flash BIOS)
Self Test Yes
Page Mode Full Page Mode Printing (Simultaneous 4 Orientation Printing: 0°, 90°, 180°, 270°)
Line and Box Draw; Bitmap Graphics; Printer Resident (Stored in Flash) Graphics
Paper Loading Manual
Paper Feed Automatic
Media Direct Thermal, Top Coated, Fanfolded and Perforted
Paper Specification 66mm W x 156mm L
4.5 mil, 1 Color/2 Colors
Bezel Control Two High Current Ticket Printing Bezel Control Ports
User Interface 4 LED Indicators, Paper Advance Button
Update Port Allows for Printer Upgrades via USB Download Port
Hot Swappable 100%
