Operators and Technicians Manual
2011 – 2014 FutureLogic, Incorporated. All Rights Reserved. MNL Page 48 04/10/2014
MNL-000067 REV.X03
Item P/N Description
1 100-00330-100 ASSY,LID,GEN3 1 -
2 100-00330-101 ASSY,LID,GEN3 - 1
3 100-00333-100 ASSY,BRKT,BASE,SLIDE 1 -
4 100-00333-101 ASSY,BRKT,BASE,SLIDE - 1
5 100-00334-100 SUBASSY,CHASSIS,BASE 1 -
6 100-00334-101 SUBASSY,CHASSIS,BASE - 1
7 100-00337-100 ASSY, PRESENTER LOWER, GEN3 1 1
8 140-00183-XXX PWB-MAIN-GEN3 1 1
9 150-00204-100 CABLE ASSY, GND, 3 POINT 1 1
10 362-00186-1XX DECAL-LID-GEN3 1 1
11 362-00187-1XX LBL-TRAY-GEN3 1 1
12 370-00371-100 PAPER TRAY (TICKET TRAY) 1 -
13 370-00371-101 PAPER TRAY (TICKET TRAY) - 1
14 370-00373-100 PIN,HINGE 1 -
15 370-00373-101 PIN,HINGE - 1
16 370-00376-100 HINGE,BASE 1 -
17 370-00376-101 HINGE,BASE - 1
18 473-00031-1XX SCR,MACH,PNHPH,4-40x1/4 2 2
19 473-00078-1XX SCR,PNHPH,PLASTITE 48-2,#4x1/4 2 2
20 473-00234-1XX SCR,PNHPH,PLASTITE 48-2,#4x3/8 2 2
21 473-00437-1XX SCR,PNHPH,PLASTITE 48-2,#4x1/2 4 4
22 473-00454-1XX SCR,FLHPH,PLASTITE 48-2,#4X3/8 2 2
23 473-00550-1XX SCR,PLASTITE,FLHPH#6X1/4 UNDERCUT 4 4
24 476-00043-1XX NUT,HEX,6-32,SP,KEPS 1 1
25 485-00163-100 SPR,HINGE,LID,GEN3 1 1
