Galil DMC-21x3 User Manual

16 • Chapter 3 ICM-20100 DMC-21x3 Accessories
J10 Aux Encoders 25-pin Female D-Sub J11 I/O 25-pin Male D-Sub
1 Reset * 1 Ground
2 AB- W 2 Latch X/Input 1
3 AA- W 3 Latch Z/Input 3
4 AB- Z 4 Input 5
5 AA- Z 5 Input 7
6 AB- Y 6 Abort *
7 AA- Y 7 Output 1
8 AB- X 8 Output 3
9 AA- X 9 Output 5
10 5V 10 Output 7
11 5V 11 Ground
12 +12V 12 NC
13 NC 13 NC
14 Error Output * 14 5V
15 AB+ W 15 Latch Y/Input 2
16 AA+ W 16 Latch W/Input 4
17 AB+ Z 17 Input 6
18 AA+ Z 18 Input 8
19 AB+ Y 19 Encoder-compare output
20 AA+ Y 20 Output 2
21 AB+ X 21 Output 4
22 AA+ X 22 Output 6
23 Ground 23 Output 8
24 Ground 24 5V
25 -12V 25 NC
* Active Low Signal
