Appendix B Mating D-Shells
The below table lists mating connector part numbers for all daughterboards. The gender is referenced to the mating
connector.
Pins Gender Density Daugtherboards Part Number
9 Female low SDM-20240, SDM-206x0 AMP 747905-2
15 Female low ICM-20100, ICM-20105, AMP-20340/1 AMP 747909-2
25 Female low ICM-20100, AMP-20240, AMP-20340/1, SDM-206x0 AMP 747913-2
25 Male low ICM-20100, ICM-20105 AMP 747912-2
37 Male low ICM-20105 AMP 747916-2
15 Male high AMP-204x0, AMP-205x0 Kycon K86-EA-15P
44 Male high AMP-204x0, AMP-205x0 Kycon K86-BA-44P
