Galil DMC-21x3 User Manual

DMC-21x3 Accessories Chapter 9 AMP-20540/20520• 51
Pinout
J4 - X-axis 15-pin HD Female D-sub J5 - Y-axis 15-pin HD Female D-sub
01 I+ X 01 I+ Y
02 B+ X 02 B+ Y
03 A+ X 03 A+ Y
04 AB+ X 04 AB+ Y
05 GND 05 GND
06 I- X 06 I- Y
07 B- X 07 B- Y
08 A- X 08 A- Y
09 AA- X 09 AA- Y
10 Hall X A 10 Hall Y A
11 AA+ X 11 AA+ Y
12 AB- X 12 AB- Y
13 Hall X B 13 Hall Y B
14 Hall X C 14 Hall Y C
15 5V 15 5V
J6 - Z-axis 15-pin HD Female D-sub J7 - W-axis 15-pin HD Female D-sub
01 I+ Z 01 I+ W
02 B+ Z 02 B+ W
03 A+ Z 03 A+ W
04 AB+ Z 04 AB+ W
05 GND 05 GND
06 I- Z 06 I- W
07 B- Z 07 B- W
08 A- Z 08 A- W
09 AA- Z 09 AA- W
10 Hall Z A 10 Hall W A
11 AA+ Z 11 AA+ W
12 AB- Z 12 AB- W
13 Hall Z B 13 Hall W B
14 Hall Z C 14 Hall W C
15 5V 15 5V

Galil DMC-21x3 Specifications

General

Brand	Galil
Model	DMC-21x3
Category	Controller
Language	English
