Galil DMC-21x3 User Manual

DMC-21x3 Accessories Chapter 9 AMP-20540/20520• 53
J1 Power (8-pin) J11 – Analog Input- 16 pin IDC Header
1 Earth 01 GND 09 Analog Input 7
2 +VDC (18V-60V) 02 GND 10 Analog Input 8
3 +VDC (18V-60V) 03 Analog Input 1 11 GND
4 +VDC (18V-60V) 04 Analog Input 2 12 GND
5 GND
05 Analog Input 3 13 -12V
6 GND
06 Analog Input 4 14 +12V
7 GND
07 Analog Input 5 15 5V
8 GND
08 Analog Input 6 16 GND
Mating Connectors
Connector Terminal Pins
J1: DC Power
Connector
8-pin Mini Universal
MATE-N-LOK
AMP# 770579-1 AMP# 170361-1
JX1, JY1, JZ1, and
JW1: 4-pin Motor
Lead Connector
4-pin Mini Universal
MATE-N-LOK
AMP# 172167-1 AMP# 170361-1
