DMC-21x3 Accessories Chapter 12 PCM-20900• 73
Chapter 12 PCM-20900
____________________________________________________________________________
Introduction
The PCM-20900 is a module that can be used to facilitate the design of a custom daughter
board. The module contains the 96 pin connector allowing it to connect to the DMC-21x3. The
user can then test the operation of circuitry before committing to a daughter board design. If
you need more information for designing your own daughter board, please refer to application
note #1232 (http://www.galilmc.com/support/appnotes/econo/note1232.pdf).
Please also note that if for some reason, the standard daughter boards do not provide the
required options, you may contact Galil for pricing regarding Galil designed custom daughter
boards.
Figure 34 PCM-20900
