DMC-21x3 Accessories Chapter 13 DB-28040• 77
Pinout
J1 – 40 Digital I/O (50-Pin IDC Header)
1 Bank 4 – Bit 40 2 Bank 5 – Bit 41
3 Bank 4 – Bit 39 4 Bank 5 – Bit 42
5 Bank 4 – Bit 38 6 Bank 5 – Bit 43
7 Bank 4 – Bit 37 8 Bank 5 – Bit 44
9 Bank 4 – Bit 36 10 Bank 5 – Bit 45
11 Bank 4 – Bit 35 12 Bank 5 – Bit 46
13 Bank 4 – Bit 34 14 Bank 5 – Bit 47
15 Bank 4 – Bit 33 16 Bank 5 – Bit 48
17 Bank 3 – Bit 32 18 Bank 6 – Bit 49
19 Bank 3 – Bit 31 20 Bank 6 – Bit 50
21 Bank 3 – Bit 30 22 Bank 6 – Bit 51
23 Bank 3 – Bit 29 24 Bank 6 – Bit 52
25 Bank 3 – Bit 28 26 Bank 6 – Bit 53
27 Bank 3 – Bit 27 28 Bank 6 – Bit 54
29 Bank 3 – Bit 26 30 Bank 6 – Bit 55
31 Bank 3 – Bit 25 32 Bank 6 – Bit 56
33 Bank 2 – Bit 24 34 GND
35 Bank 2 – Bit 23 36 GND
37 Bank 2 – Bit 22 38 GND
39 Bank 2 – Bit 21 40 GND
41 Bank 2 – Bit 20 42 GND
43 Bank 2 – Bit 19 44 GND
45 Bank 2 – Bit 18 46 GND
47 Bank 2 – Bit 17 48 GND
49 5 V 50 GND
J3 – 8 Analog Inputs (16-Pin IDC Header)
1 GND 2 GND
3 Analog Input 1 4 Analog Input 2
5 Analog Input 3 6 Analog Input 4
7 Analog Input 5 8 Analog Input 6
9 Analog Input 7 10 Analog Input 8
11 GND 12 GND
13 -12 Volt Supply 14 +12 Volt Supply
15 5 V 16 GND
