Galil DMC-21x3 User Manual

DMC-21x3 Accessories Chapter 5 SDM-20240/20242• 27
Chapter 5 SDM-20240/20242
______________________________________________________________________________
Introduction
The SDM-20240 and SDM-20242 are stepper driver modules capable of driving up to four bipolar
two-phase stepper motors. The current is selectable with options of 0.5, 0.75, 1.0, and 1.4
Amps/Phase. The SDM-20242 is the replacement for the SDM-20240 as of December 2006.
Figure 12 SDM-20240 shown mounted to a DMC-2143-DIN-DC24

Galil DMC-21x3 Specifications

General

Brand	Galil
Model	DMC-21x3
Category	Controller
Language	English
