GPSMAP 4000 Series Owner’s Manual 29
VIeWInG InformatIon
VieWinG
i
nformation
DSC Log—displays a list of all DSC calls, sorted by most recent, sender, or by type (distress calls or
position reports).
View By Time—shows the most recent DSC calls received, sorted and listed chronologically by
time and date. Calls with identical time and date information show the same information in the
list.
View By Sender—shows an alphanumerical list of senders.
View By Type—shows the most recent distress calls or position reports, sorted chronologically.
Delete All—deletes all log entries
DSC Call List—displays the 100 most-recent calls. The DSC Call List shows the most recent call
from a boat. If a second call is received from the same boat, it replaces the rst call in the Call List.
Directory—displays a list of all DSC entries. You can view by name or by MMSI. You can also add
an entry.
Viewing Gauges
To view analog or digital engine gauges from the Home screen, select Information > Engine.
NOTE: You must be connected to a NMEA 2000 network capable of sensing engine data to view the
gauges. For more information on supported NMEA 2000 PGN information, see the GPSMAP 4000/5000
Series Installation Instructions.
To select analog or digital gauges:
1. To view the Gauges from the Home screen, select Information > Engine.
2. To select analog or digital gauges, select Menu from the Engine Gauges screen, and then select
Digital or Analog.
To reset the odometer (located on the speedometer), select Reset Odometer.
NOTE: For more than two engines, you can only use the digital gauges. For one or two engines, you
can switch between analog and digital gauges
•
•
•
•
