2.4.1 Port Menus
Selecting <1> Port on the Main menu takes you to the Port Selection menu where the user selects a port to
configure, enable/disable, view statistics, or display the current data being transferred (using the built-in
Protocol Monitor). The Port Menu (Figure 2-5) displays a list of the DS2000-TS ports listing the port
number and port name along with a prompt asking the user to specify a port. Entering a port number presents
the user with the Port Function menu (Figure 2-7) showing the functions that are available on that port.
Figure 2-5. Port Menu
There is an advanced menu selection accessible from the Port Menu called the Port Status menu, and
shown in Figure 2-6. The advanced menu shows the current status of all ports and is reached by pressing
<Enter> while in the Port Menu. From the Port Status menu, the user may either select the port number to
jump to the Port Function screen or press <Esc> to exit to the Port Selection menu.
*** Port Menu ***
Port Name
E0 Ethernet S13 SERIAL-S13 S29 SERIAL-S29
S0 Sync/Async S14 SERIAL-S14 S30 SERIAL-S30
CON Console S15 SERIAL-S15 S31 SERIAL-S31
10 Virtual PAD S16 SERIAL-S16 S32 SERIAL-S32
S1 SERIAL-S1 S17 SERIAL-S17
S2 SERIAL-S2 S18 SERIAL-S18
S3 SERIAL-S3 S19 SERIAL-S19
S4 SERIAL-S4 S20 SERIAL-S20
S5 SERIAL-S5 S21 SERIAL-S21
S6 SERIAL-S6 S22 SERIAL-S22
S7 SERIAL-S7 S23 SERIAL-S23
S8 SERIAL-S8 S24 SERIAL-S24
S9 SERIAL-S9 S25 SERIAL-S25
S10 SERIAL-S10 S26 SERIAL-S26
S11 SERIAL-S11 S27 SERIAL-S27
S12 SERIAL-S12 S28 SERIAL-S28 Enter Port Number:
_________[DynaStar_6b2c]__________
Press ESC to return to previous menu Press <RET> for port status
