Configuration Basics
Terminal Server Configuration Example
DS2000-TS Administrator’s Guide
3 - 5
Figure 3-5. Advanced Terminal Server Configuration Menu
4. If using the reverse terminal server feature, toggle the IP-ASY field which will then display ASY-
IP and the Remote Socket and Remote IP Address fields will also need to be completed.
5. Repeat the previous step for all other serial ports to be configured for Terminal Server.
6. Cursor down to the Process selections field, ensure that a Y is displayed in the field and press
<Enter>.
7. Save changes to Flash by pressing <CTRL-W>.
*** Advanced Terminal Server Configuration ***
Last changed: 0-0-90 0:00:00
Port Name Type Local Remote Remote FR (Fixed) VRRP
(14) Socket Socket IP Address Port DLCI V.R.ID
S0 Sync/Async IP-ASY 10003
S1 SERIAL-S1 ASY-IP 10101 0.0.0.0
S2 SERIAL-S2 ASY-IP 10102 0.0.0.0
S3 SERIAL-S3 IP-ASY 10103
S4 SERIAL-S4 IP-ASY 10104
S5 SERIAL-S5 IP-ASY 10105
S6 SERIAL-S6 IP-ASY 10106
S7 SERIAL-S7 IP-ASY 10107
S8 SERIAL-S8 IP-ASY 10108
S9 SERIAL-S9 IP-ASY 10109
S10 SERIAL-S10 IP-ASY 10110
S11 SERIAL-S11 IP-ASY 10111
S12 SERIAL-S12 IP-ASY 10112
S13 SERIAL-S13 IP-ASY 10113
S14 SERIAL-S14 IP-ASY 10114
_________[DynaStar_6b2c]__________ Process selections (Y/N): Y
<RET> to toggle or type value Press ESC to return to previous menu
Cursor up/down for more entries Use <CTRL-D> to delete entry
To Next Page
