Port Functions
Configuration
DS2000-TS Administrator’s Guide
A - 11
Figure A-9. Console Port Configuration Menu
Table A-5. Console Port Menu
Console Port Parameters
Parameter Definition Default Range
Port The internally assigned port identification. CON IS-232 N/A
Port Name The display name for this port within the Supervisor
application menus
Console 14 alphanumeric
characters
Speed Speed of the RS-232 port 9600 Baud Toggle values
300 bps -
230.4 Kbps
Parity Parity setting for console port. 7-EVEN Toggle values
7 - auto/even/odd/
mark/space
8 - even/odd/mark/
space/none
Inactivity Timer Timer for inactivity, after which the port will be
logged off automatically. Note that this is also the
value used for Telnet sessions and it is not
recommended to set this value to 0. A hung Telnet
session could lock-out the console until the
DS2000-TS
is restarted.
5 minutes 0 (disable), 1-30
min (applies to both
Tx and Rx traffic),
31-255 min
(applies to Tx traffic
only)
*** Console Port Configuration ***
Port: CON IS-232
Port Name: Console (14)
Line Speed: 9600 Baud
Parity 7-EVEN
Inactivity timer: 30 (0, 1-30min, 31-255 out)
_________[DynaStar_6b2c]__________ Process selections (Y/N): Y
Use <TAB> and CURSOR to move fields Press ESC to return to previous menu
Use <CTRL-D> to delete entry
To Next Page
